محل منبع: | چین |
---|---|
نام تجاری: | Taizhou KAD Electromechanical Co., Ltd. |
گواهی: | CE |
شماره مدل: | ME900-1 |
مقدار حداقل تعداد سفارش: | 1 واحد |
قیمت: | $800-$1000/unit |
جزئیات بسته بندی: | پالت آهن و فیلم پلاستیکی |
زمان تحویل: | 15 روز |
شرایط پرداخت: | L/C، D/A، D/P، T/T، Western Union، MoneyGram |
قابلیت ارائه: | 50 واحد |
ظرفیت بالابر: | 130 کیلوگرم | حداکثر ارتفاع کار: | 4-10 متر |
---|---|---|---|
حداکثر ارتفاع پلتفرم: | 9 متر | طول: | 1.34 متر |
عرض: | 0.85 | ارتفاع: | 2 متر |
اندازه پلتفرم: | 0.60*0.55 متر | ردپاي خروجي: | 1.70*1.67 |
وزن ((AC): | 370 کیلوگرم | ||
برجسته کردن: | 9m Portable Lifter,10m Portable Lifter,8m Portable Lifter,10m Portable Lifter,8m Portable Lifter |
Multiple Height Options:
Available in various lifting heights (10m to 6m), users can select the right model based on their operational needs, whether for high shelving, elevated platforms, or maintenance work.
Lightweight & Portable:
Designed for easy transport and setup, the lifter can be moved by a single operator. Its compact frame fits through standard doorways and elevators, making it suitable for indoor and outdoor use.
Stable and Durable Structure:
Constructed with high-strength aluminum alloy or steel (depending on model), the lifter ensures maximum safety and long-term durability, even under frequent use.
Easy Operation:
With simple control buttons and safety mechanisms, operators can quickly raise and lower the platform with minimal training required.
Wide Range of Applications:
Perfect for logistics centers, electrical installations, building maintenance, and equipment handling in tight or elevated areas.
Model | ME600-1 | ME800-1 | ME900-1 | ME1000-1 | ||
Lift capacity | kg | 130 | 130 | 130 | 130 | |
Platform occupancy max | 1 | 1 | 1 | 1 | ||
Working height max | m | 8 | 10 | 11 | 12 | |
Platform height max | m | 6 | 8 | 9 | 10 | |
Stowed length | m | 1.34 | 1.34 | 1.45 | 1.45 | |
Stowed width | m | 0.85 | 0.85 | 0.85 | 0.85 | |
Stowed height | m | 2 | 2 | 2 | 2 | |
Platform size | m | 0.60*0.55 | 0.60*0.55 | 0.60*0.55 | 0.60*0.55 | |
Outrigger Footprint | m | 1.70*1.67 | 1.70*1.67 | 1.93*1.77 | 1.93*1.77 | |
Ground clearance | m | 0.05 | 0.05 | 0.55 | 0.05 | |
Lifting motor(AC) | kw | 0.75 | 0.75 | 0.75 | 0.75 | |
Weight(AC) | kg | 370 | 390 | 400 | 420 | |
Optional Configurations |
Power source | V/ah | 24/80 | 24/80 | 24/80 | 24/80 |
Lifting motor(DC) | kw | 0.8 | 0.8 | 0.8 | 0.8 | |
Charger | V/ah | 24/15 | 24/15 | 24/15 | 24/15 |
Time-Saving: Quickly set up and lift materials or personnel, reducing manual labor and boosting productivity.
Space-Efficient: Slim profile and folding arms make storage and transportation hassle-free.
Cost-Effective: Durable design and multipurpose functionality provide long-term value with low maintenance needs.
Safety Checks: Ensure ground conditions are stable and all safety locks are engaged before operation.
Weight Limit Compliance: Do not exceed the rated load capacity for each model height.
Regular Maintenance: Keep moving parts clean and check for any wear on lifting cables and wheels.
